Refractories Bricks

Precision Lining for Extreme Protection.

High-Quality Refractory Bricks for Industrial Applications

Our refractory bricks are engineered to withstand extreme temperatures and harsh industrial environments. Made from premium materials, these bricks offer exceptional thermal insulation, chemical resistance, and mechanical strength, making them ideal for lining furnaces, kilns, incinerators, and other high-temperature processing equipment.

Signature Refractory bricks are manufactured using state-of-the-art technology to ensure consistent quality and performance. Whether you need acid-resistant bricks for chemical processing or high-alumina bricks for steel production, we have the perfect solution for your specific requirements.

Key Features and Benefits

Exceptional thermal stability up to 1800°C (3272°F)
High resistance to thermal shock and abrasion
Low thermal conductivity for improved energy efficiency
Excellent chemical resistance to acids and alkalis
Custom sizes and shapes available for specialized applications
Long service life reducing maintenance costs
Environmentally friendly materials and manufacturing process

Our refractory bricks are widely used in industries such as steel, cement, glass, petrochemical, and power generation. With our extensive experience in refractory solutions, we can help you select the right brick type for your specific operating conditions and performance requirements.

High Alumina Bricks Specifications

Chemical Analysis

CHEMICAL ANALYSIS	SIGNATURE 55	SIGNATURE 60	SIGNATURE 65	SIGNATURE 70	SIGNATURE 75
AI2O3 % min	55	60	65	70	75
Fe2O3 % min	4	4	4	4	4

Physical Properties

PHYSICAL PROPERTIES	SIGNATURE 55	SIGNATURE 60	SIGNATURE 65	SIGNATURE 70	SIGNATURE 75
B.D. (Gm/cc) min.	2.4	2.55	2.6	2.65	2.7
A.P. % max	23	23	23	23	22
C.C.S. (Kg/Cm2) min.	400	430	450	500	600

Thermal Properties

THERMAL PROPERTIES	SIGNATURE 55	SIGNATURE 60	SIGNATURE 65	SIGNATURE 70	SIGNATURE 75
P.C.E.(OOC) min.	33	34	34.5	35	36
R.U.L. (Ta0C at 2kg/Cm2) min.	1440	1470	1460	1470	1480
P.L.C. % max	±1.5 at 1450 OC / 2 hrs.	±1.5 at 1500 OC / 2 hrs.	±2 at 1500 OC / 2 hrs.	±2 at 1500 OC / 2 hrs.	±2.5 at 1500 OC / 2 hrs.

Standard Brick Dimensions

STD BRICK	SIDE ARCH	END ARCH
9"x6"x3"	9"x6"x3"/2.5",2"	9"x4.5"x3"/2.5"/2"
9"x4.5"x3"	9"x4.5"x3"/2.75"	9"x4.5"x3"/2.75"
9"x4.5"x2.5"	9"x4.5"x3"/2.5"	9"x4.5"x3"/2.5"
9"x4.5"x2"	9"x4.5"x3"/2"	9"x4.5"x3"/2"
9"x4.5"x1.5"	9"x4.5"x3"/1.5"	9"x4.5"x3"/2"/1.5"
9"x4.5"x1"

All the sizes mentioned above will be available according the quality.

High Alumina Bricks Comprehensive Specifications

PROPERTIES	SIGNATURE 55	SIGNATURE 60	SIGNATURE 65	SIGNATURE 70	SIGNATURE 75
CHEMICAL ANALYSIS
AI2O3 % min	55	60	65	70	75
Fe2O3 % min	4	4	4	4	4
PHYSICAL PROPERTIES
B.D. (Gm/cc) min.	2.4	2.55	2.6	2.65	2.7
A.P. % max	23	23	23	23	22
C.C.S. (Kg/Cm2) min.	400	430	450	500	600
THERMAL PROPERTIES
P.C.E (OOC) min.	33	34	34.5	35	36
R.U.L. (Ta0C at 2kg/Cm2) min.	1440	1470	1460	1470	1480
P.L.C. % max	±1.5 at 1450 OC / 2 Hrs.	±1.5 at 1500 OC / 2 Hrs.	±2 at 1500 OC / 2 Hrs.	±2 at 1500 OC / 2 Hrs.	±2.5 at 1500 OC / 2 Hrs.
